IGBT Invertor Technology.
Dual Digital Meters.
Stepless Voltage & Wire Speed Setting
Electronic Choke Adjustment for Better Arc Control.
Crater Voltage & Time Setting
Pre & Post Gas flow Setting.
Burnback Setting Available.
IP 23 Compliance
Automobile Industry
E-mobilty Mfg.
Sheet Metal Fabrication
Furniture
GMAW (Mig)
SMAW (Stick)
GTAW (TIG)
|
MODEL MIG 250 F |
|
|
Technical Parameter |
Value |
|
Input Supply |
230 Vac +/- 10% 1 Phase / 400 V +/- 15 3 Phase, 50/60Hz |
|
Input Power |
11 kVA |
|
Output Current Range |
20 – 250 A |
|
Output Voltage Range |
14 – 28 Vdc |
|
Duty Cycle % |
1 Phase 200A @ 60% / 3 Phase 250A @ 60% |
|
Open Circuit Voltage |
75 Vdc |
|
Dimensions (LxWxH) |
501x275x465 mm |
|
Weight |
16.2 Kg |
