IGBT Invertor Technology
HF Arc Ignition
Digital Ampere Meter
Stepless Current Control
AC Waveforms Square/ Sine / Triangular
Pre & Post gas Flow Function
UP & Down Slope Function
Initial & Crater Current Selection
Pulse Frequency Selection
2T / 4T Function
AC Frequency Adjustment
Compatible to Generator Supply
IP 23 Compliance.
Water Cooling Unit (Optional)
Aerospace
Shipbuilding
Pipe and Tube Fabrication
Aluminium Fabrication
GTAW (TIG)
GTAW-P (Pulsed TIG)
SMAW (Stick)
|
MODEL TIG/MMA 400 |
|
|
Technical Parameter |
Value |
|
Input Supply |
400Vac +/- 15% 3 Phase, 50/60Hz |
|
Input Power |
13.8 kVA |
|
Output Current Range |
15 – 315 A |
|
Duty Cycle % |
60 % |
|
Open Circuit Voltage |
75 Vdc |
|
Dimensions (LxWxH) |
515x275x465 mm |
|
Weight |
30 Kg |
