IGBT Invertor Technology with Excellent Line Voltage Compensation
Stepless Control of Current
Weld Time 0.01 to 4.0 sec
Operator Friendly Front Panel Controls with Digital Meter
Simple Circuit Easy for Maintenance
Construction Site
Steel Bridge Mfg.
Heat Exchanger
Deck Sheet Welding
Stud Welding
|
MODEL HERCULES 2500 |
|
|
Technical Parameter |
Value |
|
Input Supply |
400Vac +/- 15% 3 Phase, 50/60Hz |
|
Input Power |
99 kVA |
|
Output Current Range |
100 - 2500 A |
|
STUD Dia |
Ø 6 - 25 |
|
Duty Cycle % |
80 % |
|
Open Circuit Voltage |
32 Vdc |
|
Dimensions (LxWxH) |
780x355x870 mm |
|
Weight |
97 Kg |
